C and E Brother’s Steel Factory PLC


Phone +251 111 26 21 07
Phone 2 +251 111 26 21 43
Fax +251 111 26 21 13
Mobile +251 911 672174
Mobile 2 +251 911 170131
Mobile 3 +251 947 636363 or 0947 656565
LocationInfront of Tikur Ambesa School Tracon Tower 7th Floor Office No 701, Addis Ababa, Ethiopia
Primary CategorySteel Products
C and E Brother’s Steel Factory PLC

C & E Brother’s Steel Factory P.L.C is one of the leading suppliers of TMT reinforcement bars of Grade 40 and Grade 60 & 75 in Ethiopia. The factory produces ribbed bars in different diameters i.e 8mm, 10mm, 12mm, 14mm, 16mm, 20mm, 24mm & 32mm. The factory also produces Silica Ramming Mass or Quartz to steel factories and paint factories.

C & E Brother’s Steel Factory PLC was established in according with the commercial code of Ethiopia at 1960 and registered with the Ethiopia Investment Agency Licensing and Registration Department on August 14, 2008.
It is a joint venture factory of Ethiopian investors with a total establishment capital of more than 1 Billion Ethiopian birr.

C and E Brothers Steel Factory PLC is located in the southern part of the capital city of Ethiopia, Addis Ababa, in a town called Bishoftu which is 45 km from A.A

The factory was built on a total area of 30,000 m3, which is later expanded to 90,000 m2. The factory's total annual production capacity is more than 500,000 Metric tone.

CNE1

Company Strategy

  • Purpose:- To be a leader in reinforcement manufacturing industry by providing enhanced service and relationship
  • Vision :-  To provide a service that excepts the expectation of our esteemed customer
  • Mission:- To build long term relationship with our customer and clients and provide exceptional customer service by pursuing business through innovation and advanced technology

Core values

  • We believe in treating our customers with respect and faith
  • We grow through creativity invention
  • We integrate honesty, integrity and business ethics into all aspects of our business function

Goals

  • Regional expansion in the reinforcement industry and develop a strong base of key customers. Increase the asset and investment of the company to support the development of service
  • To build good reputation in the field of steel industry and become a key player in the industry

Production Capacity

It produces different size of reinforcement bars used mainly for construction industry with different grades. Currently, the factory produces two types of products.Reinforcement bars with attainable capacity of 54,000 ton per annum and Silica Ramming Mass with capacity of 18,000 ton per annum.

Product Manual

C & E Brother’s Steel Factory PLC ensure with its quality assurance processes. The following material properties conform to the standards indicated below.

Grade 40

Mechanical Properties

      •  Yield Strength Max: 300Mpa
      •  Tensile Strength: 330 Mpa
      •  Elongation: 16%

Grade 60

 Mechanical Properties

      • Yield Strength Max : 500Mpa
      • Tensile Strength : 550 Mpa
      • Elongation : 14%

Structural Property

Net Area is computed using effective width concept for design purposes.
Design strength: fyd = fyk / 1.15=278MPA
In addition to sectional properties of Ribbed Reinforcement bars produced by  C &E Brother’s steel factory; it includes the following design and reinforcement detailing aids:

  • Table showing Maximum Numbers of Reinforcement bars in one Row of Beams
  • Table showing Areas of Reinforcement for Beams, Columns, Slabs and Foundation
  • Table showing Anchorage and Lap Lengths Requirements

Chemical Property

For Grade 40

  • Carbon = 0.22
  • Silicon < 0.4
  • Manganese < 1.5
  • Phosphorus < 0.05
  • Sulpher  < 0.05

For Grade 60

  • Carbon = 0.25
  • Silicon < 0.4
  • Manganese < 1.5
  • Phosphorus < 0.05
  • Sulpher  < 0.06



Products and Services(1 Images)
